1756-M02AE ControlLogix Analog Motion Modules - Rockwell Automation



The Allen-Bradley 1756-M02AE is an analog encoder (AE). This module has two axes and a quadrature-position feedback output. This module controls drives or actuators that need either a +/- 10V velocity or a torque reference input. It ensures that the actuator (motor) follows the profile by monitoring the position feedback via the quadrature encoder input. It also generates an analog command reference for the drive.

The input type of the 1756-M02AE module is an encoder input with incremental AB quadrature and a marker. The encoder mode has a 4X quadrature and a maximum encoder rate of 4 MHz counts per second.

This module has 5V or 24V position registration inputs. Its current draw is 700 mA at 5.1V DC and 2.5 mA at 24V DC with a module power of 3.63 W. The module’s power dissipation is 5.5 W and its electrical interference is 5V differential (optically isolated). It has an on-state voltage range of 3.4 to 5V and an off-state voltage range of 0 to 1.8V.

It also has an optically-isolated, current sinking input type. Its nominal voltage is 24V DC. The on-state minimum voltage is 17V DC, the maximum on-state is 26.4V DC, and the maximum off-state voltage is 8.5V DC.
