Allen Bradley 1756-OF8 analog output module

Allen Bradley 1756-OF8 analog output module , features Eight (8) output channels, configurable for +/-10VDC Voltage and 0-20 mA Current output signals


  • Delivery Time2 days
  • Warranty12 months

Products Description:

1756-OF8

Analog output module, ControlLogix product.

features Eight (8) output channels, configurable for +/-10VDC Voltage and 0-20 mA Current output signals



Technical Informations:

1756-OF8

Outputs Eight voltage or current

Output range, ± 10V , 0…20 mA

Resolution , 15 bits across 21 mA - 650 nA/bit

15 bits across , 10.4V - 320 V/bit

Current draw @,  5.1V 150 mA

Current draw @ , 24V 210 mA

Total backplane power , 5.8 W

Voltage and current ratings Backplane: , 5.1V DC, 150mA max, 24V DC, 210mA max

Output Voltage, -10…+10V

Output Current, 4…20mA

Power consumption , 5.8 W backplane power

Power dissipation , 5.8 W to 3.15 W; 0 to 750 ohm loads

Thermal dissipation , 16.78 BTU/hr

Overvoltage protection , 24V DC

Drive capability Voltage,  > 2000 

Current., …750 

Settling time,  < 2 ms to 95% of final value with resistive loads

Calibrated accuracy, @ 25 °C (77 °F) Better than 0.05% of range from 4…21 mA, -10.4…10.4V

Calibration interval , 12 months typical.



About this item:

1.100% New Original Factory Sealed

2.Best price

3.Warranty for 12 months



Advantage:

1.Large stocks

2.Warehouse about the country, choose the nearest storehouse to dispatch your goods.

3.Cooperated logistic express company, offer cheapest air courier fee

4.Provide global brands products,quality assurance!

Allen Bradley 1756-OF8



Payment Terms:

Wire transfer (100% T/T)



Special discount:

If you find other suppliers offer cheaper price for same product, we`d love to offer you the same, or even more disocunt.



Packaging & Delivery:

1.Original factory sealed package.

2.Wrap with foam with every item.

3.Carton package in advance.

4.For heavy cargo, will load with wooden package.

5.Fast delivery after payment

6.Air way through DHL/FedEx/UPS/TNT...
