Products Description:
1756-OW16I output module
Digital Output, 16 Channel, 125VDC, 125/240VAC
Technical Specifications
1756-OW16I
Outputs ,16 N.O. individually isolated
Pilot duty ,C300/R150
Operating voltage range ,5…125V DC, 0…240V AC
Output voltage range (load dependent) 1 A @ 5…30V DC
0.5 A @ 48V DC
0.22 A @ 125V DC
1.5 A @ 120V AC 50/60 Hz
0.75 A @ 240V AC 50/60 Hz
Output delay time
Off to On
On to Off
10 ms max
10 ms max
Current draw ,@ 5.1V 150 mA
Current draw ,@ 24V 150 mA
Total backplane power, 4.4 W
Power dissipation, max 4.5 W @ 60 °C (140 °F)
Thermal dissipation ,15.35 BTU/hr
Off-state leakage current per point, max 1.5 mA per point
Minimum load current ,10 mA per point
Initial contact resistance, max 100 mΩ @ 6V 1 A
About this item:
1.100% New Original Factory Sealed
2.Best price
3.Warranty for 12 months
Advantage:
1.Large stocks
2.Warehouse about the country, choose the nearest storehouse to dispatch your goods.
3.Cooperated logistic express company, offer cheapest air courier fee
4.Provide global brands products,quality assurance!
Payment Terms:
Wire transfer (100% T/T)
Special discount:
If you find other suppliers offer cheaper price for same product, we`d love to offer you the same, or even more disocunt.
Packaging & Delivery:
1.Original factory sealed package.
2.Wrap with foam with every item.
3.Carton package in advance.
4.For heavy cargo, will load with wooden package.
5.Fast delivery after payment
6.Air way through DHL/FedEx/UPS/TNT...
