Product Details:
- Number of digital inputs: 16
- Time delay at signal exchange: 8 ms
- Type of voltage (input voltage): DC
- Type of electric connection: Screw connection
- Nominal Impedance: 3 kOhm
- Number of commons: 2
- Heat dissipation, max: 5.4 W @ 30V
- Bus current draw, max： 70 mA @ 5V DC (0.35 W)
- ON-state current, max： 12.0 mA @ 30V DC
- Power supply distance rating：6 (the module may not be more than 6 modules away from the system power supply)
- On-state current, nom： 8.0 mA @ 24V DC
- Isolated groups：Group 1: inputs 0...7, Group 2: inputs 8...15
- Input group to backplane isolation：Verified by one of the following dielectric tests: 1200V AC for 1 s or 1697V DC for 1 s 75V DC working voltage (IEC Class 2 reinforced insulation)
- Width：40.4 mm
- Height：90 mm
- Depth：87 mm
- Weight：230 g
- Shock：Operating: 30G panel mounted, 3 pulses per axis, Relay Operation: 7G
- Vibration Operating: 10 to 500 Hz, 5G, 0.030 in. max. peak-to-peak, 2 hours per axis Relay Operation : 1.5
