Product Details:
- Output Specifications
- Load range on voltage output：>1KΩ
- Output update time: Typical: 2.5 ms
- Number of outputs：4 single-ended (unipolar)
- D/A converter type：R-2R ladder voltage switching
- Non-linearity：< ±0.59% (in percent full scale)
- Typical overall accuracy：±1.17% full scale @ -20...65 °C (Only applicable to Series B I/O modules.)
- Reactive load, voltage output：<1 μF
- Reactive load, current output：<0.1 mH
- Output protection：-32 mA
- Open and short-circuit protection：Continuous
- Resistive load on current output： 0...500 Ω (includes wire resistance)
- Output ripple range：<±0.1% @ 0...500 Hz (referred to output range)
- General Specifications
- Analog normal operating range：Voltage: 0...10V DC
- Bus current draw, max： 40 mA @ 5V DC, 165 mA @ 24V DC
- Full scale analog ranges Voltage: 0...10.5V DC, Current: 0...21 mA
- Repeatability：-0.12 to 0.12%
- Input and output group to system isolation：30V AC/30V DC rated working voltage (IEC Class 2 reinforced insulation) type test: 500V AC or 707V DC for 1 minute
