Specifications
| Manufacturer |
Rockwell Automation |
| Brand |
Allen-Bradley |
| Part Number/Catalog No. |
20BD096A0ANNANC0 |
| Voltage |
480V AC |
| Phases |
3 |
| Precharge |
- |
| Amps |
96 |
| HP |
75 |
| Frame |
5 |
| Enclosure |
IP20, NEMA/UL Type 1 |
| Operator Interface |
Blank Cover |
| Documentation Type |
Manual |
| w/Brake |
No |
| w/Resistor |
No |
| CE Filter |
Yes |
| CM Choke |
Yes |
| Network Type |
None |
| Control |
Vector |
| I/O Volts |
24V DC/AC |
| Feedback Type |
None |
The Allen-Bradley 20BD096A0ANNANC0 is an AC drive. It belongs to the PowerFlex 700 series of drives. The 20BD096A0ANNANC0 operates with 3-phase power rated at 480 Volts AC input. The output of the drive is rated for 96 Amps and 75 Horsepower in normal duty mode and for 60 Horsepower in heavy-duty mode. Single-phase AC input leads to de-rating and only 50% of the rated power is available at drive output with that power. The 20BD096A0ANNANC0 does not contain either an integrated HMI module or a communications module. However, numerous optional modules are available for adding an HMI and communication modules. It also does not include a drive-mounted brake resistor or a brake IGBT. A CM choke and a CE filter are included.
The 20BD096A0ANNANC0 supports vector control algorithm with 24 Volts DC I/O. Feedback is not supported. The range of output voltage is from 0 to the motor rated voltage. The range of output frequency is from 0 to 420 Hertz. The drive provides Class 10 motor overload protection and motor over-temperature protection. The 20BD096A0ANNANC0 is available in a frame 5, conformal-coated IP20 NEMA Type 1 enclosure. The storage and working temperature ranges are from -40 to 70 degrees Celsius and from 0 to 50 degrees Celsius, respectively. The drive must only be installed in an environment which is free from corrosive elements. The velocity of the heatsink fan is 200 DFM. The sound level of an operating drive is 71 dB. The total power dissipation is 1107 Watts. The 20BD096A0ANNANC0 weighs 82 pounds. Its dimensions are 27.15 x 12.16 x 10.84 inches.
