Allen-Bradley 20F11ND034JA0NNNNN

The 20F11ND034JA0NNNNN built by Allen Bradley (AB) is a 25 Horsepower unit. Furthermore, this drive also uses 480 VAC to operate. This drive comes with a dynamic brake if braking is required, has no keypad unit, instead the drive a blank HIM cover, and optional communication slot on the drive. In addition, this PowerFlex 753 (750 series) variable frequency drive has a NEMA UL Type Open enclosure type rating. Also, this Allen Bradley (AB) variable frequency drive has an amperage rating of 34 A.

The 20F11ND034JA0NNNNN is an Allen-Bradley/Rockwell Automation drive from the PowerFlex 753 family. It is an AC drive which is manufactured with prior precharge and it runs with a 480 Volts AC supply. The supply is drawn from a 3-phase electrical source. It runs with 34 Amps of current. It is an air-cooled drive solution and it is an open type of device. The drive can operate with both normal and heavy-duty load conditions. Under a normal load condition, the drive has a power output of 25 Horsepower and under a heavy load condition, the drive can produce a power output of 20 Horsepower. The 20F11ND034JA0NNNNN meets all the EMC requirements and it is also certified with a CE standard. The drive features 1 analog input which is isolated, bipolar, and differential. It can only work with +/-10 Volts supply. The drive has an 88-kiloohm input impedance. The drive features control input/output which can detect analog loss, timed outputs, and PTC input.

The 20F11ND034JA0NNNNN features an Ethernet/IP port for internal communication purposes. Using the communication port, the drive can be set to work with the manufacturing process it is made to be a part of. The communication can be seen from the LED indicators located on the front panel of the drive. The Ethernet/IP port supports adapter routing. It lets users plug into 1 drive and communicate with other compatible Allen-Bradley devices which are on the same network without needing to be routed through the network scanner. The 20F11ND034JA0NNNNN features support for both speed regulation and torque regulation. The slip compensation feature can deliver a 0.5% speed regulation without making use of any encoder feedback devices. The drive also features droop control. This feature helps to share the load without any intervention between each other. With the encoder feedback device in place, the drive can provide 0.001% speed regulation and it can hold the speed at zero speed.
