Allen-Bradley 20F11ND040AA0NNNNN

The 20F11ND040AA0NNNNN is a PowerFlex 753 adjustable frequency AC drive. This drive is compatible with 3-Phase, 400VAC and 480VAC voltage classes specifically, 342VAC-440VAC and 432VAC-528VAC supply voltage input ranges. It has an output voltage ranges of 0VAC-400VAC for 400V class and 0VAC-460VAC for 480VAC class. For 400V class input, the drive’s Normal duty output ratings are 40 A and 22kW while for Heavy Duty, output ratings are 37 A and 18.5kW. For 460VAC, the drive’s Normal duty output ratings are 43 A and 30HP while for Heavy Duty, output ratings are 51 A and 25HP.

The Allen-Bradley 20F11ND040AA0NNNNN refers to the PowerFlex 753 Adjustable Frequency AC drive. This drive has an input supply voltage of 3-Phase, 400VAC and 480VAC voltage classes specifically, 342VAC-440VAC and 432VAC-528VAC supply voltage input ranges. The drive’s output voltage ranges are 0VAC-400VAC for 400V class and 0VAC-460VAC for 480VAC class. The output ratings of the drive varies according to the supply voltage used specifically, for 400V class input, the drive’s Normal duty output ratings are 40 A and 22kW while for Heavy Duty, output ratings are 37 A and 18.5kW. For 460VAC, the drive’s Normal duty output ratings are 43 A and 30HP while for Heavy Duty, output ratings are 51 A and 25HP.

The entire PowerFlex 750 drives, including the PowerFlex 753 has embedded DeviceLogix, Predictive Diagnostics, Option Cards, SafeTorque-Off, Safe Speed Monitor, Integrated Safety-Safe Torque Off, Communication features.

The 20F11ND040AA0NNNNN supports installation of option communication module such as the dual Ethernet communication adapter. This communication adapter supports fast ethernet and gigabit ethernet speed that enables the 20F11ND040AA0NNNNN to communicate with partner devices such as Programmable Logic Controllers (PLC) and Programmable Automation Controllers (PAC) and visualization devices. This same communication network is used to directly integrate the drive to the user program which allow full integration of the entire drive’s parameters including diagnostic tags.

It also incorporates three option slots for connecting I/O.

The auxiliary control power of the 20F11ND040AA0NNNNN PowerFlex drive provides support when there is power loss from the main supply. It also provides automatic feedback loss switchover, and it features universal, encoder, and dual encoder feedback options with multiple feedback interfaces to support a wide range of applications such as; Incremental, SSI, and BiSS rotary-linear applications, EnDat and Hiperface for Stegmann and Heidenhain high-resolution feedback. For safety requirements, the 20F11ND040AA0NNNNN PowerFlex 753 AC drive features DriveGuard Safe Torque-Off, safe speed monitor, and embedded safety relay safety options like the Insulated-Gate Bipolar Transistor (IGBT), the Pump Jack, and the Pump Off options for oil well applications. Upon each startup, the drive runs preventive diagnostics to detect and prevent possible downtime during machine operation, and the conformal coating of its components and its IP00/IP20 enclosure protect the drive from dust and corrosive gases.
