Specifications
| Manufacturer |
Rockwell Automation |
| Brand |
Allen-Bradley |
| Part Number/Catalog No. |
20F1AND186JA0NNNNN |
| Series |
PowerFlex 753 |
| Frames |
6...8 |
| Enclosure Type |
AC Input w/Precharge, no DC Terminals |
| Frames 2 |
2...7 |
| Enclosure Type 2 |
IP20/IP00, NEMA/UL Type Open |
| Voltage |
480V AC/650V DC |
| Filtering |
Yes |
| Default CM Cap Connection |
Jumper Installed |
| Internal Resistor |
No |
| Internal Transistor |
Yes |
The 20F1AND186JA0NNNNN drive is a PowerFlex 753 variable frequency AC drive manufactured by Allen-Bradley/Rockwell Automation. The drive is engineered to receive 480 Volts AC input voltage, but it can be also be supplied with 650 Volts DC. The power rating of the unit is 186 kilowatts (150 Horsepower). The 20F1AND186JA0NNNNN drive requires very little maintenance, but it must be installed correctly in environments with ambient temperatures of less than 50 degrees Celsius, coupled with the correct motor that has the appropriate power size, and wired with the motor by using shielded cables. The speed regulation is conducted by using the sensorless vector control or vector control with FORCE technology. The drive is delivered with a jumper installed for default CM cap connections.
The Allen-Bradley 20F1AND186JA0NNNNN drive supports filtering and has multiple protection mechanisms. The unit is protected against 6000 Volts AC line transient voltages, short-circuits, high voltages and currents, ground faults, and overvoltage in DC circuits. With this AC drive installed, the motor itself will generate less stress on the electrical power supply system through an improved power factor, reduced in-rush current, and less significant harmonics. With additional cards that can be installed in the drive, this speed controller can become part of network controlled systems which provides configuration and troubleshooting possibilities. The 20F1AND186JA0NNNNN drive is a frame 6 sized drive that supports dynamic braking (with internal transistors), weighs 39 kilograms, and has an IP 00 rated (open) enclosure.
