This Allen-Bradley/Rockwell Automation 156A PF755 frequency drive is a 125 HP (horsepower) rated unit. Furthermore, this module has no HIM unit included, instead the drive comes with a blank HIM cover. In addition, this PF755 frequency drive comes with the jumper removed on the drive however a jumper can be installed. This PowerFlex 750 (PF755) AC drive features 5 option slots installed on the drive. Additionally, it comes with power requirements of 480 VAC, is operated with VAC input with precharge, and an IP20/IP00.
The 20G1AND156AN0NNNNN drive is an Allen-Bradley AC drive and it is classified under the Allen-Bradley PowerFlex 755 AC drive series. The 20G1AND156AN0NNNNN falls under the 480 Volts AC voltage class and it is a 3-phase drive. It features an output current of 156 Amps with 125 Horsepower normal duty power output and 100 Horsepower heavy-duty power output. The 20G1AND156AN0NNNNN comes with the open type enclosure that features AC input with precharge but no DC terminals. The 20G1AND156AN0NNNNN comes with the CM jumper removed and it has the filtered EMC filtering options. It has no specified dynamic braking and it features a blank slot where an HMI can be installed.
The 20G1AND156AN0NNNNN’s design and engineering offer ease of use and flexibility. The unit can be used for various industrial applications. The Allen-Bradley PowerFlex 755 drive series features maximum flexibility and performance levels with up to 2000 Horsepower and 1500 kW. The 20G1AND156AN0NNNNN comes with the DeviceLogix™ embedded control technology for supporting the manipulation of discrete outputs as well as the drive control functions. Designed with predictive diagnostics support, the 20G1AND156AN0NNNNN tracks the information that affects the life of the drive’s cooling fans as well as the relay outputs. It is programmable for monitoring the runtime hours for the machine as well as for the motor bearings. The unit also features option cards with each drive having slot-based architecture. The supported hardware control options are also available and they help to reduce the inventory and the spare parts requirements. Allen-Bradley drives also feature a common power structure to provide similar physical sizes and power ranges.
