Specifications
| Manufacturer |
Rockwell Automation / Allen-Bradley |
| Actuation force |
10-110 g |
| Touch interface lifespan |
1 Million actuations |
| Touch Input |
8-wire analog resistive |
| Anti-Glare overlay |
not included |
| Input interface |
Touch |
| Luminance |
1000 cd/m2 (Nits) |
| Display colors |
18-bit color graphics |
| Resolution |
800 x 600 |
| Display Area |
246 x 184 mm (9.7 x 7.2 in.) |
| Display Type |
Color active matrix, thin-film transistor (TFT) with liquid crystal display (LCD) |
| Compatibility |
PanelView Plus 1000 / PanelView Plus 6 Touch terminals |
| Product Family |
PanelView Plus Graphic Terminals |
| Brand |
Allen-Bradley |
| Display Size |
12.1 inches |
| Part Number/Catalog No. |
2711P-RDT12H |
| Series |
PanelView Plus |
| Module Type |
Display Module |
| Compatible Terminal |
1250 Model Terminal |
| Touch Screen |
Analog Resistive |
| Display |
Color |
| Input Voltage |
24 Volts DC |
| Power Consumption |
70 Watts (max) |
| Weight |
7.1 pounds (3.2 kilograms) |
| Dimensions (H x W x D) |
11.12 x 14.3 x 2.9 inches |
| UPC |
10781180776813 |
The 2711P-RDT12H is a PanelView operator terminal component that is specifically used for operator terminals with High Bright display. This PanelView is compatible for use with PanelView Plus and PanelView Plus 6 1250 High-Bright displays. It is designed with a high luminance of 1000 cd/m2 (Nits.). With this High-bright display, compatible PanelView that uses this component may be installed in outdoor locations.
The 2711P-RDT12H comes with an integrated temperature sensor that is used to monitor the temperature of the operator terminal. This temperature sensor enables automatic adjustment of brightness. The 2711P-RDT12H display module may be used DC logic boards only.
The 2711P-RDT12H comes with a 12.1-inch colored display screen, having a display area of 246 x 184 mm (9.69 x 7.25 in) and pixel resolution of 800 x 600. It also carries the Analog Resistive Touchscreen operator input interface that is rated for 1 million actuations.
Similar to other display modules, the 2711P-RDT12H touchscreen display module is ideally used to be calibrated for first time use. This calibration setup may be accessed under the touchscreen properties. Similarly, the 2711P-RDT12H has an adjustable brightness and contrast.
The 2711P-RDT12H High-bright display module is especially compatible with PanelView Plus, PanelView Plus 6 high-bright operator terminal versions.
The 2711P-RDT12H may be operated at a temperature range of 0-55 °C or 32-131 °F. It can withstand vibration ratings of 10… 57 Hz, 0.012 pk-pk displacement and 57…500 Hz 2.0 g pk acceleration. This display module has an operating shock rating of 15 g at 11 ms.
