Specifications
| Display Type |
Color active-matrix TFT |
| Input Voltage range |
18-30VDC |
| Integrated ports |
Ethernet, RS-232, 2 USB host |
| Internal memory |
512MB Flash Memory / 512 MB Random Access Memory |
| Touch |
1 million presses |
| Lifecycle status |
End of life |
| Operator Input |
Touch |
| Product Family |
PanelView Plus 6 Operator Terminals |
| Manufacturer |
Rockwell Automation |
| Brand |
Allen-Bradley |
| Product Type |
PanelView Plus 6 1200 Operator Terminals |
| Display Size |
12.1 inches |
| Backlight |
CCFL, 50,000 hours min at 25 ° C (77 °F), field replaceable |
| Display Area |
246 x 184 mm (9.7 x 7.2 in.) |
| Part Number/Catalog No. |
2711P-T12C4D8 |
| Product Line |
Panelview 6 Plus |
| Input Type |
Touchscreen |
| Input Power |
18 to 32 Volts DC |
| Memory |
512 MB RAM |
| Communication Cable |
2711-NC13 |
| Shipping Weight |
10 pounds |
| Shipping Dimensions |
20 x 14 x 8 inches |
| Series |
Series A and Series B |
| Communication |
Ethernet and RS-232 |
| Display Resolution |
800 x 600, 18-bit color graphics |
| Real Time Clock (Battery) |
2711P-RY2032 (CR2032) |
| Product Weight |
7 Lbs. |
| Product Dimensions |
11.12 x 14.30 x 2.18 in. (282 x 363 x 55 mm) |
| Cutout Dimensions |
10.11 x 13.29 in. (257 x 338 mm) |
| Logic Module |
2711P-RP8D |
| Display Module |
2711P-RDT12C |
| UPC |
10612598876720 |
The PanelView Plus 6 operator terminal with catalog number 2711P-T12C4D8 belongs to the sub-category PanelView Plus 6 1250 operator terminal. This operator terminal is more commonly known as Human Machine Interface (HMI) that is used to provide process and machine operators with a centralized monitoring and control point of the system. This controls to a more accurate, efficient and responsive control and lessens the risk of human operational errors.
This electronic device is powered by an external voltage range of 18-30VDC. It also comes with an integrated memory of 512MB Random Access Memory (RAM) and 512 MB Flash Memory. The internal memories cannot be upgraded however, may be installed with memory expansion devices such as 1784-SD1 and 1784-SD2 Secure digital cards. It may also be installed with external flash drive for removable storage.
This operator terminal comes with a 12.1-inch colored graphic screen, compatible for implementing a colored graphical display of the plant including animations that depict the state of the instruments and devices. It is operated through the analog resistive touchscreen interface which allow direct interaction to the objects displayed in the runtime environment.
The approximate shipping weight and dimensions of the 2711P-T12C4D8 are 10 pounds and 20 x 14 x 8 inches. The Ethernet/IP (Ethernet Industrial Protocol) is an open industrial network that supports real-time I/O messaging, as well as message exchange. The Ethernet port connects to a controller on an Ethernet/IP network by using both the network and standard Ethernet connections. This port can work with application transfers and with printing as well. The Ethernet/IP screen displays data and allows the users to modify some of the Ethernet/IP communication settings for a PanelView terminal. The module has its own unique IP address. This port has an RJ45, 10/100Base-T connector for network communication and it supports MDI/MDI-X connections. The parameters are downloaded with the application.
