Allen-Bradley 5094-IF8

The 5094-IF8 input module is an 8-channel input module from the Allen-Bradley/Rockwell Automation Flex 5000 series. All 8 of the input channels are single-ended. The 5094-IF8 input module is a DC-powered input module. Its input voltage range is from 18 to 32 Volts DC. It has a maximum sensor-actuator or SA current rating of 120 milliamps. The 5094-IF8 input module supports Category 2 wire for its power ports and its shielded ports.

The Allen-Bradley 5094-IF8 FLEX 5000 module comes with 8 channels, and it is a current and voltage input module. The module’s 8 inputs are single-ended input channels. It uses Sigma-Delta module conversion and two 24-bit multiplexed ADC module conversion too. The 5094-IF8 module’s scan time is 360 microseconds per channel and 1.4 milliseconds per module. This current and voltage input module has the HART handheld compliance rating. It can scale to engineering units, timestamp the inputs, and handle real-time onboard data alarming and CIP Sync. The data formats that the 5094-IF8 module can use are the IEEE 754 data format and the 32-bit floating-point data format. The 5094-IF8 module uses category 2 wire for its shielded ports and for its power ports.

The Allen-Bradley 5094-IF8 FLEX 5000 8-channel module comes factory calibrated, but it can be user-calibrated too. Its maximum backplane power voltage rating is 15 Volts DC and the maximum backplane power current is 70 milliamps. The sensor actuator (SA) power voltage range for the 5094-IF8 module 18 to 32 Volts DC and its maximum sensor-actuator (SA) current rating is 120 milliamps. The maximum power dissipation rating in the current mode is 3.5 Watts and the maximum thermal dissipation rating in the current rating 11.94 BTU/hour. This module is an open module that does not come with an enclosure. The maximum surrounding air temperature that the 5094-IF8 current and voltage module can withstand is 158 degrees Fahrenheit.

The 5094-IF8 is an Analog 8-channel Current/Voltage Input Module manufactured by Allen-Bradley which has Inputs of 8 single-ended, an Input range, voltage of ±10V0...10V0...5V, and an Input range, current of 0...20 mA4...20 mA as well as a Input impedance of Voltage: >1 MΩCurrent: 250 Ω typical. The Common mode voltage (channel to channel) for this module is ±10V, and the Module conversion method is Sigma-Delta,Two 24-bit multiplexed ADC. The Backplane Power (BP) voltage for this model is 15V DC .
