Allen Bradley FLEX 1794-IB32 I/O Module
Contact: Miya
Job Title: Sales Manager
Skype: live:miyazheng520
Email: sales@amikon.cn
Tel: 86-18020776792(Whats App )
QQ :2851195450
Brand Name AB
Product reference 1794-IB32
Connect Wiring for the 1794-IB32 using a 1794-TB32 or 1794-TB32S
1. Connect individual input wiring (IN0…IN15) to numbered terminals on the 0…15
row
(A) as indicated in the Wiring Connections for 1794-IB32 table.
2. Connect the associated power to the +V1 terminal (35, 37, 39, or 41) on the
34…51 row
(C) as indicated in the Wiring Connections for 1794-IB32 table.
3. Connect the associated common for IN0…IN15 to COM1 (terminal 36, 38, 40,
or 42) on the 34…51 row
(C) as indicated in the Wiring Connections for
1794-IB32 table.
