The Allen-Bradley 1747-ASB is a remote I/O adapter module that is a part of the SLC 500 system. It establishes a communication link between SLC or PLC scanners and various 1746 I/O modules via Remote I/O. The Remote I/O link consists of one master device i.e., an SLC or PLC scanner and one or more slave devices that are adapters.




The SLC or PLC image table gets I/O module image-mapping directly from its chassis. For image mapping, it supports both discrete and block transfer. The 1747-ASB has support for 1/2-slot, 1-slot, and 2-slot addressing with efficient image utilization. It is installed in the chassis with the SLC 500 processor and it scans I/O in the chassis.




The 1747-ASB also provides non-volatile memory and extended node capability to up to 32 adapters. For wiring, the Belden 9463 or similar category cable must be used, and it does not require any user programming. It uses a 6-Pin Phoenix Connector for connection between the Remote I/O link and the processor.






Part Number: 1747-ASB
Cable: Belden 9463
Connectors: 6-Pin Phoenix Connector
Weight: 0.37 pounds (168 grams)
Dimensions: 5.72 x 1.37 x 5.15 inches
Weight : 2.5 pounds (1.1 kilograms)
Dimensions: 5.5 x 3.6 x 5.7 inches
Operating Temperature: 0-60 Celsius








Allen  Bradley  1747-ASB


Allen Bradley slc 500 1747-ASB Remote I/O Adapter Module





Email:sales3@amikon.cn





  Part Number:
  1747-ASB
  Series:   SLC 500
  Module Type:   I/O Adapter Module
  Communication Port:   Universal Remote I/O Adapter
  Communication Rate:

  57.6, 115 or 230 kilobits/second
