Aluminium Heavy Duty Lift and Slide Door with Big Size Sashes
Lift slide doors are your one-stop solution for strength and durability. With panels that rise off the track and move with ease, these doors are an upgrade from your traditional sliding glass doors. The door handle is the home of our lift slide technology; the gaskets in the door are lifted when you turn the handle, which then lifts the panels and allows them to smoothly travel across the track. Once the panels are in place, you turn the handle once more, and the door locks into place.
- SIMPLE OPERATION - Dual ball-bearing rollers, self-contained leveling adjusters, and climate-neutral performance mean easy operation, even in the toughest environments.
- CONVENIENCE - The frame is covered with a rigid vinyl sheath for durability and minimal maintenance.
- PEACE OF MIND - Solid, secure construction with multiple locking points offer an added level of security.
- COMFORT - Continuous weather-stripping and interlocking design features help keep your home draft-free and provide energy saving.
- VERSATILITY - Available in single and multi-panel configurations, as well as custom sizes.
| Parameters |
Sash Width/Height
(mm) |
Visible Width
(mm) |
Depth
(mm) |
Glass Thickness(mm) |
|
width 720-3300mm
height 1800-2700mm Weight 300kg
|
Fame Width 40mm
Sash Width 100mm
|
Frame Depth 130/190mm
Sash Depth 50mm |
SGU:
8-10mm
DGU:
24-35mm |
| Performance |
|
Heat Insulation
W(m2.k)
|
Sound Insulation
(DB)
|
Water Tightness
(Pa)
|
Air Tightness |
Wind Load
(KPA)
|
|
2.3-2.8
level 5/6
|
35DB
level 4
|
500PA
level 5
|
level 6 |
3.1KPA
level 3
|
Customized - HOMI is a aluminium manufacturer with over 30 successful years of valuable experience in this industry. Our teams bring the most professional and competitive suggestions for your engineer and design needs, providing solutions on various sizes and complex projects.
Technical Support -The independent local and abroad technology teams provide aluminium curtain walls technical support (such as wind load calculation, systems and façade optimization), installation guide.
System design -Based on the clients' and market's requirement, develop new aluminium windows and doors systems, match excellent accessories, which can better meet the client target market requirement.
Q: Are you trading company or manufacturer?
A: We are aluminium manufacturer located in QINGYUAN with more than 30 years experience. And you are warmly welcomed to visit us.
Q: How long is your delivery time?
A: Generally it is 15-20 workdays after receiving payment.
Q: Do you provide samples for free? What's the MOQ?
A: The new die samples are free for approval and inspection. The MOQ is 8-10tons
Q: What is the payment terms?
A: 30% upon order confirmation and the balance should be paid before delivery by T/T./after receiving B/L copy. /L/C at sight
