Aluminized Heat Screen with Adhesive Backing

Aluminized Heat Screen with Adhesive Backing made by aluminum and glass fiber base material, also there is a high temperature adhesive backing. Heatshield aluminum heat barrier is a reflective heat protection barrier that will protect and keep components cool in the most demanding applications.



Description

Heatshield Aluminum Heat Screen is made from fiberglass and aluminum mylar finish, and with adhesive backed.


Feature

Direct Heat Resistance: 800°F
Base glass radiant heat to 1100°F

Adhesive backing aluminum heat barrier can withstand up to 1100 degrees F of radiant heat and can withstand direct contact up to 450 degrees F.


Application

Solves the problem of heat from engines and exhaust intruding into interiors and components. Helps shield fire walls, hoods, body panels, floor boards


Specifications

Datasheet
Material Aluminum, fiberglass, adhesive
Continuous Temperature 1100 °F
Melt Temperature 2000 °F
Standard Thickness 0.8mm
Thickness 0.2mm, 0.6mm, 0.8mm, 1.0mm, 1.5mm, 2.0mm, 3.0mm
Length MAX 50 meter/roll
Color Silver
Cutting Tool Scissor



Part Number Description
251212 12 in × 12 in
251224 12 in × 24 in
251250 12 in × 50 in
251818 18 in × 18 in
252424 24 in × 24 in
252448 24 in × 48 in
252640 26 in × 40 in
253658 36 in × 58 in
254036 40 in × 36 in
254050 40 in × 50 in
254046M 40 in × 164 ft

Notes:

Other size upon request.

Bluk rolls upon request.

Custom packages upon request.
