Aluminum Foil Coated Fiberglass Heat Reflective Sewn Sleeve

SEALFS sewn type Aluminum Coated Fiberglass Heat Reflective Sleeve is a fabric sewn aluminized fiberglass sleeve, a highly polished aluminum foil is calendared under high pressure and with an adhesive onto a high temperature fiberglass base fabric.  That fabric is slit into an tape, which is then sewn into a sleeve.



Description

SEALFS Aluminum Foil Coated Fiberglass Heat Reflective Sewn Sleeve is a layer of aluminum foil under fiberglass base fabric,and sewn with high temperature thread into a sleeve. This sleeve is easily to install due to the smooth inner fiberglass surface and reflects more then 95% radiant heat.


Features

This high temperature, heat resistant and radiant heat reflective sleeve can be used to protect industrial wires, cables, hoses (hydraulics), piping and tubing from radiant heat sources such as glowing steel slab, liquid metal pour stream, infrared heaters and other similar sources.


Application

It is used to protect the industry & automotive wires, cables, hydraulic hoses, piping and tubing from radiant heat sources.


Specifications

DATASHEET
Part Number Normal Inside diameter Meter for spool
Inches mm Dash # Meter
SEALFS-13 1/2 13 -8 20
SEALFS-16 5/8 16 -10 20
SEALFS-19 3/4 19 -12 20
SEALFS-22 7/8 22 -14 20
SEALFS-25 1 25 -16 20
SEALFS-29 1 1/8 29 -18 20
SEALFS-32 1 1/4 32 -20 20
SEALFS-35 1 3/8 35 -22 20
SEALFS-38 1 1/2 38 -24 20
SEALFS-41 1 5/8 41 -26 20
SEALFS-44 1 3/4 44 -28 20
SEALFS-48 1 7/8 48 -30 20
SEALFS-51 2 51 -32 20
SEALFS-57 2 1/4 57 36 20
SEALFS-60 2 2/5 60 -38 20
SEALFS-64 2 1/2 64 -40 20
SEALFS-67 2 5/8 67 -42 20
SEALFS-70 2 3/4 70 -44 20
SEALFS-73 2 7/8 73 -46 20
SEALFS-76 3 76 -48 20
SEALFS-83 3 1/4 83 -52 20
SEALFS-89 3 1/2 89 -56 20
SEALFS-95 3 3/4 95 -60 20
SEALFS-102 4 102 -64 20


Technical Datasheet
Material Aluminum, fiberglass
Working temperature -40 - +260
Flammability VW-1
Melting point +537
Standard Color Silver
Standard Thickness 0.8 mm
MOQ 100 meter each size
Cutting tool Scissors

Notes:
Special thickness upon request
Special length or packing upon request.
Special size upon request.
