Z series intelligent nuts color sorting machine
-
Precise equipment with double cameras.
Among them, the front and rear view can be equipped with visible and double
infrared cameras (optional)
-
Using the latest CCD tri-chromatic and optional
infrared sensors, customized lens, high-speed FPGA data processor and
high-speed ejectors, and use the easy-to-operate human-machine interface with
touch screen.
-
High-tech product with light, mechanism, electricity and air.
The impurities can be automatically removed from the sorting raw material.
-
High sorting accuracy, high efficiency, easy operation, compact
structure and elegant appearance, mainly used in the field of cereals sorting.
Machine parameter
Main
technical parameters ，take peanuts with less than 10% impurities as an example：
|
Model
|
Capacity（T/h）
|
Accuracy
|
Carryover
|
Power（kw)
|
Voltage
|
Dimension
|
Weight（kg）
|
|
Z1
|
1.2-2
|
≥98%
|
＞20:1
|
0.3-0.5
|
220V/50HZ
|
1141*1576*1927
|
350
|
|
Z2
|
2.4-4
|
≥98%
|
＞20:1
|
0.4-0.65
|
220V/50HZ
|
1456*1576*1927
|
500
|
|
Z5
|
6-12
|
≥98%
|
＞20:1
|
0.7-1.1
|
220V/50HZ
|
2307*1549*1719
|
1100
|
|
Z7
|
8-14
|
≥98%
|
＞20:1
|
1.1-1.9
|
220V/50HZ
|
2937*1549*1719
|
1350
|
|
Z8
|
9-16
|
≥98%
|
＞20:1
|
1.3-2.2
|
220V/50HZ
|
3252*1549*1719
|
1500
|
|
Z10
|
12-20
|
≥98%
|
＞20:1
|
1.4-2.3
|
220V/50HZ
|
4045*1549*1719
|
1750
|
Note：Reserve the right to change the parameters
without prior notice
-
Multi-type chutes with anodizing treatment to ensure smooth material flow,improve machine sorting performance,meet different requirement from customers.
-
High efficient and durable LED lamps ensures long life span of the sorter. True RGB controllable background assembly applied to cleaning and grading of muitiple materials.
-
Compound image algorthm realizes intelligent and accurate identification from color ,texture,shape,size and material.
-
High definition low distortion lens “copys” the real information into machine visual system. 5400 px RGB trichromatic CCD sensor & Infrared CCD sensor analyze full spetrum from the material.
-
High-end imported INTEL ALTERA “Cyclone” IV generation FGPA chips bring huge speed capacity of data processing and exchange max as100 mega byte per second.
-
12” LCD touch screen and Windows based system equipped with most simplified interface and remote control and mobile devices control Only for easy operation.
-
Compact Magnev high frequency ejectors ensures the quality of accepted products after sorting,reduce the rate of good kernel inside of rejected products and consumption of compressor.
-
Food grade water proof vacuum inner package and seaworthy wooden box ensure safety of the cagos delivery from whatever tremendous change of sea shipping conditions meet.
Design and offer various type of sorter according to different customers' requirement and material features,to achieve the optimal sorting performance.
This Grain color sorter can reach both color sorting and shape sorting functions
