Android Handheld Wire 1D laser Barcode Scanner IPBS060

qr reader
1.Trial order acceptable
2.High quality, reasonable
3.Reasonable Price



Parameter
Light Source Visible laser 650nm
Error Rate 1/5million
Safety Accord with China National Laser Safety
Decoding Capability

UPC-A, UPC-E, EAN-13, EAN-8, ISBN/ISSN, Code39, Code Bar, Interleaved / ITF 25, Industrial 25,Code 128

Code 93Code 11MSI/PIESSEY UCC/EAN128

Interface USB ,RS232 ,PS/2
Trigger Mode Manual, Automatic induction, Continuous scanning
Transmission Speed RS232  baudrate: 1200-19200
Scanning Width Min 0.1mm(4mils)
Scanning Depth 2—9cm(0.1mm Width),3—50cm(0.3mm Width)
Scanning Speed 200scans / sec
Scanning Distance 10-600mm  Roll 60º, Pitch45º
Operating Temp. -20ºC―50ºC
Storage Temp. -20―60
Operating Humidity 0―95%
Storage Humidity 5%―95%
Power Supply DC 5V±5%
Operating Current 50ma(Operating),30ma(Stand By),100ma(Max)
Quiescent Current 20mA
Shock Resistance 1.5m free fall on concrete surface
EMI en8001,par1
Ingress Protection iec529,ip42
Language multiple languages
Casing Size 167*96*64MM
Material ABS+PVC+PC
