Anti fog self cleaning Coating is Clear,colorless liquid.Used in the manufacture of Anti fog self cleaning Coating.If you want to know more,please contact sales@sinogracechem.com
Features
Strong fog resistance
Good adhesion
Qualification
Appearance :Transparent liquid
Density（g/cm2）: 0.8-1.0
Coating thickness（μm）: 5-8
Leveling temperature/time（℃ : 60℃
UV Curing Energy（J/cm*cm）: 480-550
Application
PC sheets
Detection methods and performance indicators
|
Testing items
|
Test method
|
Result
|
|
Initial droplet angle
|
3-5 ml water, tested in 10 seconds
|
< 10 degrees
Scratch free
No fogging
No fogging
|
|
Dry film adhesion
|
Berg test
|
＞4B
|
|
Wet film adhesion
|
80 degrees steam fumigated nail scratch
|
Scratch free
|
|
Steam test
|
Place for 5 seconds at 10 cm above 80 C water vapor
|
No fogging
|
|
Steam test
|
Place it 10 cm above 80 C steam for 10 minutes, dry naturally, observe the appearance, and then do anti-fogging test.
|
No fogging
|
HOW TO USE for Anti fog self cleaning Coating
Before cleaning: wipe the PC board with absolute ethanol.
Spraying process: The sample can be uniformly sprayed on the sample plate with a disposable dropper, then placed vertically, and baked in a 60 degree oven for 3 minutes.
Curing process: UV curing, energy between 480-550 J/cm*cm.
