ASA5525-K8 Overview
Midsize businesses protecting the Internet edge require the same level of protection as large, enterprise networks. You require enterprise-strength security, but purchasing a firewall that was built to handle the performance needs and budget of a large enterprise would be unnecessary and a waste of company resources. You need a firewall that provides the performance you need at a price you can afford, without compromising security.Cisco ASA 5500 series adaptive security appliance fits your network and budget while offering the same proven level of security that protects some of the largest networks at some of the most security-conscious companies in the world. The ASA 5500 series scales to meet the performance and security requirements of a wide range of network applications, to correspond with your changing needs.The Cisco ASA 5525-X is midrange security appliance that uses the Cisco SecureX framework for a context-aware approach to security that delivers multiple security services, multigigabit performance, flexible interface options, and redundant power supplies. It is built on the same proven security platform as the rest of the ASA family of security appliances, and has been designed to deliver superior performance for exceptional operational efficiency.
ASA5525-K8 Specification
General
|
|
Device Type
|
Security
appliance
|
Height (Rack Units)
|
1U
|
Width
|
16.9
in
|
Depth
|
15.6
in
|
Height
|
1.7
in
|
Weight
|
14.99
lbs
|
Processor /
Memory / Storage
|
|
RAM
|
8
GB
|
Networking
|
|
Form Factor
|
Rack-mountable
|
Ports Qty
|
8
|
Connectivity Technology
|
Wired
|
Data Link Protocol
|
Gigabit
Ethernet
|
Performance
|
Firewall
throughput: 2 Gbps ¦ VPN throughput (3DES/AES): 300 Mbps ¦ Connection rate:
20000 connections per second ¦ Firewall + intrusion prevention throughput:
600 Mbps
|
Capacity
|
IPSec
VPN peers: 750 ¦ SSL VPN peers: 2 ¦ Concurrent sessions: 500000 ¦ Virtual
interfaces (VLANs): 200 ¦ Security contexts: 2
|
Status Indicators
|
Power,
HDD activity, active, alarm
|
Features
|
Firewall
protection, VPN support, VLAN support, High Availability
|
Encryption Algorithm
|
DES
|
Expansion /
Connectivity
|
|
Expansion Slots
|
1
(total) / 1 (free) x expansion slot
|
Interfaces
|
8
x 1000Base-T - RJ-45 ¦ 1 x 1000Base-T (management) - RJ-45 ¦ 1 x management -
RJ-45 ¦ 2 x USB 2.0 - Type A
|
Miscellaneous
|
|
Rack Mounting Kit
|
Included
|
Compliant Standards
|
VCCI,
C-Tick, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, EN55022 Class A, CISPR
22, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 B Class A, CAN/CSA C22.2
No. 60950-1-07, ANSI C63.4-2009
|
Power
|
|
Power Device
|
Internal
power supply
|
Installed Qty
|
1
|
Max Supported Qty
|
1
|
Voltage Required
|
AC
120/230 V (50/60 Hz)
|
Power Provided
|
400
Watt
|
Software /
System Requirements
|
|
Software Included
|
Drivers
& Utilities
|
Manufacturer
Warranty
|
|
Service & Support
|
Limited
warranty - 90 days
|
Environmental
Parameters
|
|
Min Operating Temperature
|
23
°F
|
Max Operating Temperature
|
104
°F
|
Model No
|
ASA5525-K8
|
Warranty
|
1
year
|
Lead time
|
2-3
business days
|
Shipment
|
DHL,
Fedex, Aramex, EMS or per request
|
