ASA5525-K9 Overview
Midsize businesses protecting the Internet edge require the same level of protection as large, enterprise networks. You require enterprise-strength security, but purchasing a firewall that was built to handle the performance needs and budget of a large enterprise would be unnecessary and a waste of company resources. You need a firewall that provides the performance you need at a price you can afford, without compromising security.Cisco ASA 5500 series adaptive security appliance fits your network and budget while offering the same proven level of security that protects some of the largest networks at some of the most security-conscious companies in the world.
ASA5525-K9 Specification
|
Networking
|
|
|
Type
|
Security
appliance
|
|
Form Factor
|
Rack-mountable
|
|
Connectivity Technology
|
Wired
|
|
Data Transfer Rate
|
2
(Gbps)
|
|
Data Link Protocol
|
Gigabit
Ethernet
|
|
Status Indicators
|
Active,
Alarm, Boot state, HDD activity, Power, VPN
|
|
Ports Qty
|
8
|
|
Features
|
Firewall
protection, High Availability, VLAN support, VPN support
|
|
Network Transport Protocol
|
IPSec
|
|
Interface
Provided
|
|
|
Qty
|
8
|
|
Type
|
Management
|
|
Connector Type
|
RJ-45
|
|
Service
|
|
|
Support Details Type
|
Limited
warranty
|
|
Support Details Service Included
|
Advance
parts replacement
|
|
Support Details Full Contract Period
|
90
days
|
|
Miscellaneous
|
|
|
Rack Mounting Kit
|
Included
|
|
Compliant Standards
|
C-Tick,
CISPR 22, CSA C22.2 No. 60950-1-07 Second Edition, EMC, EN 60950-1, EN
61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC Part 15 B Class A,
ICES-003, IEC 60950-1 Second Edition, KC, UL 60950-1 Second Edition, VCCI V-3
|
|
Height (Rack Units)
|
1
|
|
Encryption Algorithm
|
DES,
Triple DES
|
|
Environmental
Parameters
|
|
|
Min Operating Temperature
|
23
°F
|
|
Max Operating Temperature
|
104
°F
|
|
Humidity Range Operating
|
0
- 90%
|
|
Header
|
|
|
Compatibility
|
PC
|
|
Manufacturer
|
Cisco
Systems
|
|
Packaged Quantity
|
1
|
|
Product Line
|
Cisco
ASA
|
|
Model
|
5525-X
Firewall Edition
|
|
Brand
|
Cisco
|
|
Modem
|
|
|
Type
|
None
|
|
Power Device
|
|
|
Frequency Required
|
50/60
Hz
|
|
Nominal Voltage
|
AC
120/230 V
|
|
Type
|
Internal
power supply
|
|
Service &
Support
|
|
|
Type
|
90
days warranty
|
|
Service &
Support Details
|
|
|
Response Time
|
10
days
|
|
Slot Provided
|
|
|
Total Qty
|
1
|
|
Free Qty
|
1
|
|
Software
|
|
|
Type
|
Cisco
VPN Client
|
|
Capacity
|
|
|
Type
|
Virtual
interfaces (VLANs)
|
|
Value
|
200
|
|
Performance
|
|
|
Type
|
VPN
throughput (3DES/AES)
|
|
Value
|
300
Mbps
|
|
Dimensions
& Weight
|
|
|
Width
|
16.9
in
|
|
Depth
|
15.6
in
|
|
Height
|
1.7
in
|
|
Weight
|
14.93
lbs
|
|
Expansion
Slots
|
|
|
Type
|
Expansion
slot
|
|
Optical
Storage
|
|
|
Type
|
None
|
|
RAM
|
|
|
Installed Size
|
12
GB
|
|
Model No
|
ASA5525-K9
|
|
