ASR1000-ESP200 Overview
The Cisco ASR 1000 series Embedded Services Processors (ESPs) are based on the innovative, industry-leading Cisco QuantumFlow processor for forwarding and queuing in silicon.The Cisco ASR 1000 Series ESPs are responsible for the data-plane processing tasks, and all network traffic flows through them. The modules perform all baseline packet routing operations, including MAC classification, Layer 2 and Layer 3 forwarding, Quality-of-Service (QoS) classification, policing and shaping, security access control lists (ACLs), VPNs, load balancing, and NetFlow. They are also responsible for features such as firewalls, intrusion prevention, Network-Based Application Recognition (NBAR), Network Address Translation (NAT), and Cisco IOS flexible pattern matching.
ASR1000-ESP200 Specification
|
General
|
|
|
Brand
|
Cisco
|
|
Product Code
|
Cisco ASR1000-ESP200
|
|
Depth
|
14.2 in
|
|
Height
|
0.8 in
|
|
Networking
|
|
|
Form Factor
|
Plug-in module
|
|
Connectivity Technology
|
Wired
|
|
Performance
|
Bandwidth: 200 Gbps ¦ Encryption
throughput: 78 Gbps ¦ Forwarding performance: up to 130 Mpps
|
|
Capacity
|
Access control entries: 400000 ¦
Concurrent L2TP VPN tunnels: 64000 ¦ ACL rules: 4000 ¦ IPv4 routes: 4000000 ¦
IPv6 routes: 4000000 ¦ NAT/ firewall sessions: 6000000 ¦ QoS hardware
entries: 232000 ¦ GRE tunnels: 4000
|
|
Status Indicators
|
Power, active, standby, status
|
|
Features
|
Firewall protection, NAT
support, IPv6 support, Access Control List (ACL) support, Quality of Service
(QoS)
|
|
Miscellaneous
|
|
|
Compliant Standards
|
ETSI, BSMI CNS 13438 Class A,
CISPR 24, EN 60950, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, VCCI Class A
ITE, IEC 60950, EN55024, EN55022 Class A, UL 60950, CISPR 22, EN50082-1, EN
61000-4-2, EN 61000-4-6, AS/NZ 3548 Class A, CSA C22.2 No. 60950-00, EN
50082-2, EN 61000-4-11, FCC CFR47 Part 15, EN300-386, NEBS
|
|
Manufacturer
Warranty
|
|
|
Service & Support
|
Limited warranty - 90 days
|
|
Environmental
Parameters
|
|
|
Min Operating Temperature
|
41 °F
|
|
Max Operating Temperature
|
104 °F
|
|
Humidity Range Operating
|
5 - 85%
|
|
Compatibility
Information
|
|
|
Designed For
|
Cisco ASR 1013
|
|
Warranty
|
One year
|
|
Lead time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex, EMS or per
request
|
