Main
|
|
Range of product
|
Altivar
|
|
Product or component type
|
Variable speed drive
|
|
Product specific application
|
Simple machine
|
|
Component name
|
ATV11
|
|
Application market
|
Asia
|
|
Assembly style
|
With heat sink
|
|
EMC filter
|
Without EMC filter
|
|
Built-in fan
|
Without
|
|
Network number of phases
|
Single phase
|
|
[Us] rated supply voltage
|
200...240 V - 15...10 %
|
|
Supply frequency
|
50...60 Hz - 5...5 %
|
|
Motor power kW
|
0.37 kW
|
|
Line current
|
6 A at 200 V, Isc = 1 kA
|
|
Nominal output current
|
1.4 A 230 V motor 4 kHz
|
|
Maximum transient current
|
3.6 A for 60 s
|
|
Power dissipation in W
|
25 W at nominal load
|
|
Complementary
|
|
Product destination
|
Asynchronous motors
|
|
Supply voltage limits
|
170…264 V
|
|
Network frequency limits
|
47.5…63 Hz
|
|
Speed drive output frequency
|
0…200 Hz
|
|
Nominal switching frequency
|
4 kHz
|
|
Speed range
|
1…20
|
|
Transient overtorque
|
150...170 % of nominal motor torque
|
|
Environment
|
|
Standards
|
EN 50178
|
|
IP degree of protection
|
IP20
|
|
Ambient air temperature for storage
|
-25…65 °C
|
