Automated True Density Tester For True Density, True Size, Measured Skeletal Density, Open Porosity, Obturator Porosimetry
SPECIFICATIONS
L380 cm * W280 cm * H280cm
Net Weight﹤10kg
Technical parameters:
1. Principle: gas displacement method;
2. Test function:true density, true size, measured skeletal density, open porosity, obturator porosimetry;
3. Test Range: 0.0001 g/ml- - no upper limit;
4. Analysis station: one sample analysis station;
5. Sample cell volume:10ml, 100ml volume cells, you can choose it according to your samples tested;
6. Test accuracy≤ 0.03%;
7. Repeatability: ≤ ± 0.01%;
8. Test Resolution: 0.0001g / ml;
9. Pressure Accuracy: imported high-precision pressure sensors;
10. Test efficiency: one sample test average is about 3-5 minutes; the test times can be set automatically;
11. Sample types: powders, granules, blocks, foam and other solid samples, and syrupy substance, non-volatile non-corrosive liquids and other samples;
12. Test gas: helium or nitrogen;
13. Test temperature range: room temperature;
14. Control program: fully automated control, simple and easy application; set USB interface, easy to export data; intelligent self-test, check the sample cell sealing automatically, excluding human error;
15. Instrument Design: Integrated design, LCD touch screen control and display systems, high-performance, high-quality, small footprint, equipped with computers, cost savings;
16. Power Requirements: AC 220V ± 20V, 50Hz, power 100W.
