Product Name: Automatic 4ft spindleless high speed wood core veneer peeling machine and cutting
Major Technical Parameters
|
DESCRIPTION
|
UNIT
|
BQ1813/G5GSI-J
General
|
|
Length of log
|
mm
|
900-1400
|
|
Diameter of log
|
mm
|
Φ32-Φ550
|
|
Length of blade
|
mm
|
1500
|
|
Thickness of veneer
|
mm
|
0.8-4.0
|
|
Width of cut veneer
|
mm
|
500-3000
|
|
Linear speed of host machine
|
m/min
|
45-82m/min
60-110m/min
|
|
Diameter of driving roller
|
mm
|
122
|
|
Diameter of pressurebar roller
|
mm
|
143
|
|
Diameter of rubber roller
|
mm
|
140
|
|
Power of pressurebar
roller
|
kw
|
11
15
|
|
Power of double roller
|
kw
|
11
15
|
|
Power of cutting feed
|
kw
|
11
15
|
|
Power of shear
|
kw
|
3
|
|
Power of PU roller/ output converyor
|
kw
|
1.5
|
|
Total power
|
kw
|
37.5
49.5
|
|
Total weight
|
kg
|
5500
|
|
Overall dimensions
|
mm
|
3900*2500*1600
|
Main Features:
1. Automatic servo motor
2. High and adjustable speed of from 45-110m/min
3. Double roller feed to guarantee the thickness and width's accuracy
4. Strong casting frame of machine to increase the stability
