Main Function:
To make the irregular in the work site regular automatically, then fed into pallet feeding machine one by one for the block making line recycling use.
Main Technical Features:
1. Automatic pallets feeding machine adopts adjustable pallet frame structure, all models are suitable for brick machine pallet.
2. Full hydraulic system, sent to board more convenient, more simple and more flexible.
3. Imported PLC computer program control: the forced board, manual feed plate. Brick, sent to board aircraft synchronized, continuous work. Truly production, sent to board, lift-automatic synchronization. Fully automated, intelligent, humane, safe and efficient.
4. The pallets unloaded can be stacked randomly at the same direction, which can save much time for block unloading and pallet collecting.
5. Piler height reaches 1 m, which can save transfer time for forklift and production cost.
6. Piler will not need to feed pallet manually any more, which can reduce labor force and save 2 operators.
Technical Parameter:
|
Power:
|
6.7 kw
|
|
External Size:
|
2940*2550*2500 mm
|
|
pallet Size:
|
1350*880 mm
|
|
Piler Max height:
|
1 m
|
|
Piler Max Weight:
|
3 t
|
