Product Description:
X20DI9371
I/O module
12 digital inputs 24 VDC for 1-wire connections
Digital inputs:
Nominal voltage, 24 VDC
Input characteristics per EN 61131-2, Type 1
Input voltage, 24 VDC -15% / +20%
Input current at 24 VDC, Typ. 3.75 mA
Input circuit, Sink
Input filter
Hardware , ≤100 μs
Software Default 1 ms, configurable between 0 and 25 ms in 0.2 ms increments
Connection type, 1-wire connections
Input resistance, Typ. 6.4 kΩ
Switching threshold
Low, <5 VDC
High, >15 VDC
Insulation voltage between channel and bus, 500 Veff
About this item:
1.100% New Original Factory Sealed
2.Best price
3.Warranty for 12 months
Advantage:
1.Large stocks
2.Warehouse about the country, choose the nearest storehouse to dispatch your goods.
3.Cooperated logistic express company, offer cheapest air courier fee
4.Provide global brands products,quality assurance!
Payment Terms:
Wire transfer (100% T/T)
Special discount:
If you find other suppliers offer cheaper price for same product, we`d love to offer you the same, or even more disocunt.
Packaging & Delivery:
1.Original factory sealed package.
2.Wrap with foam with every item.
3.Carton package in advance.
4.For heavy cargo, will load with wooden package.
5.Fast delivery after payment
6.Air way through DHL/FedEx/UPS/TNT...
