Dimensions: 23cmx3.5cmx11cm
|
Weight: 0.62KG
|
Ambient Temperature：-25°C to +95°C
|
LocalBus Power：2 to 25 VDC
|
|
·8 analog inputs
·8 analog outputs
·Connection possibility single-ended or differential
·Power supply for up to 4 potentiometers
·Temperature inputs for up to 4 Pt100/Pt1000 sensors
·2-wire or 4-wire inputs for Pt100/Pt1000 sensors
·Wire break detection for the inputs (for voltage and temperature)
·Short circuit proof outputs
·Overload detection for potentiometer power supplies
·Monitoring of the external supply voltage
|
The AIO288/1 is Analog input/output module.Especially designed for sophisticated motion control applications the ISI222 module offers compact equipment and optimum precision. Equipped for the total control of two motion axes, the module features a number of encoder interfaces for position acquisition, analog outputs for the application of manipulated variables, as well as digital inputs for the initiator or trigger.
Beside the full compatibility to the well proven controller modules M-SMC, M-CNC and M-SHAFT, also the user own programs and individually designed control tasks can utilize the extensive integrated functions of the module simply via the known standard interfaces (SVI, MIO).
|
