Battery Safety Testing Equipment Li-ion Battery Extrusion Test Machine
SPECIFICATIONS
TOB-BET-6045Battery Crush Testing Machineis a professional battery safety testing equipment, It tests battery safety performance through extrusion test, the battery should be no fire, no explosion after extrusion. It is the indispensable testing equipment for various battery manufacturers and research institute.
|
Model
|
Battery Crush Testing Machine TOB-BE-6045
|
|
Source voltage
|
AC 380V, 50/60HZ
|
|
Power
|
1500W
|
|
Warranty
|
One Year limited warranty with lifetime support
|
|
Dimension(W*D*H)
|
680*570*1740mm
|
|
Weight
|
200kg
|
|
Controller dimension
(W*D*H)
|
330*330*1040mm
|
|
Max pressure
|
1000N-13KN, Customized
|
|
Upper pressure plate diameter
|
15cm
|
|
Pressure error
|
1%
|
|
Power model
|
Hydraulic
|
|
Max test space
(D*W*H)
|
200*200*200mm
|
|
View window dimension
|
200*200mm, 10mm thickness Double explosion-proof glass
|
|
Anti explosion case
|
Bottom is provided with four universal wheels, and can move freely
|
|
Exhaust fan port
|
15mm diameter
|
PACKAGE AND SHIPPING
|
1 Standard exported package : Internal anticollision protection, external export wooden box package
2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode
3 Responsible for the damage during shipping process, change the damage part for free
4 Supply with suitable voltage input and power plug according to customer's country requirements.
|
SERVICES
|
1 We supply machines with battery technology support.
2 We can also supply a full set of materials for lithium battery including polymer battery, cylinder battery, mobile phone battery, EV battery.
3 We can also supply a full set of lithium battery equipment for lab research, pilot scale research and production line.
4 We can also supply a full set of battery technology for battery design, research and producing.
|
We cooperated with each other,
and we will do TOP OF THE BEST battery
