Penetration battery nail tester for lithium battery pouch cell safety performance testing
SPECIFICATIONS
|
Model
|
Battery Needling Testing Machine TOB-BNT-9002
|
|
Warranty
|
One Year limited warranty with lifetime support
|
|
Dimension
|
900*1460*500mm
|
|
Weight
|
150kg
|
|
Controller dimension
|
330*1040*330mm
|
|
View window dimension
|
200*200mm, 10mm thickness Double explosion-proof glass
|
|
Source voltage
|
AC 110V/220V, 50HZ
|
|
Needling mode
|
Pneumatic
|
|
Needing force
|
150-200kg，±1% accuracy
|
|
Max testing size
|
200*200*200, adjustable
|
|
High temperature resistant steel needle
|
φ3mm and φ8mm
|
|
Needling height
|
150mm
|
|
Needling speed
|
10-40mm/s, adjustable,
Through the perpendicular to the battery plate direction pierce the battery,
stop (1min~6hour) automatically from a battery pull, easy disassembly.
|
|
Anti explosion case
|
Bottom is provided with four universal wheels, and can move freely
|
|
Exhaust fan port
|
15mm diameter
|
