Battery short circuit testing machine For Lithium Battery Safety Performance Testing
SPECIFICATIONS
|
Type
|
TOB-BE-1000A
|
|
Short circuit current
|
500A 、1000A can be choose
|
|
DC Response Time
|
≤5us
|
|
Device resistance
|
≤5MOhm，can customized
|
|
Remote distance
|
7m No solid obstacle
|
|
Short circuit time
|
1~9999s or 1M~99H59M can be set
|
|
Dimension
|
W650*D730*H970mm
|
|
Explosion-proof box size
|
W500*D500*H500mm, thickness:5mm
|
|
Power supply
|
AC220V 50HZ
|
|
Power
|
1.0KW
|
|
Weight
|
About 180Kg
|
