Battery Temperature Cycling Testing Machine For Lithium Battery Safety Performance Testing
SPECIFICATIONS
|
Type
|
BE-HLK
-80M3
|
BE-HLK
-150M3
|
BE-HLK
-225M3
|
BE-HLK
-408M3
|
BE-HLK-800M3
|
BE-HLK
-1000M3
|
|
Within Volume
|
80L
|
150L
|
225L
|
408K
|
800L
|
1000L
|
|
Within
Feet(cm)
|
40*50*40
|
50*60*50
|
50*75*60
|
60*85*80
|
100*100
*80
|
100*100
*100
|
|
Working environment
|
+5~+35℃
|
|
Heater
|
Nickel-cadmium alloy strip heater
|
|
Blower
|
Centrifugal fan
|
|
Airflow mode
|
Broadband type forced air cycle (up out，down in)
|
|
Condensing mode
|
Air-cooled or water-cooled
|
|
Temperature range
|
-40℃~+150℃
|
|
Temperature fluctuation
|
±0.5℃
|
|
Rise time
|
-40~+80℃＜30min，4℃/min Average，rise and fall speed customizable
|
|
Fall time
|
+80~-40℃＜30min，4℃/min Average，rise and fall speed customizable
|
|
Box material
|
Inside:Mirror stainless steel
Outside:Mirror stainless steel or Steel spray
|
|
Insulation material
|
Rigid polyurethane foam
|
|
Controller
|
“8”show：TEMI880 Color touch smart programmable controller（Chinese-English Convertible）
“3”show：TEMI300 LCD keypad controllers（English Display）
|
|
Cooling system
|
France Taikang hermetic compressors（Environmentally friendly refrigerant）
|
|
Protection device
|
Compressor overheating, over-current, over-voltage, heating nothingr burning, over-temperature alarm system inside
|
|
Power
|
AC3∅5W 380V
|
|
Standard configuration
|
A viewing window，∅50mm Test hole，Sample holder 2set，Inside lights
4 Mobile working wheels
|
|
Option
|
Communication port，Logger，Built-in glass doors or operation hole
|
