Battery Voltage and Resistance Tester
TOB-BK-300A battery internal resistance tester is a kind of new instrument using alternating current test battery internal resistance, It can measure voltage at the same time, the operation is simple and practical.
The resistance tester adopts four-wire clamp, effectively eliminate the measuring error caused by the contact resistance, it can set unqualified alarm for resistance testing
Battery internal resistance tester For 18650 and lipo battery voltage and resistance tester .
SPECIFICATIONS
TOB-BK-300A battery internal resistance tester is a kind of new instrument using alternating current test battery internal resistance, It can measure voltage at the same time, the operation is simple and practical.
The resistance tester adopts four-wire clamp, effectively eliminate the measuring error caused by the contact resistance, it can set unqualified alarm for resistance testing
|
Machine model |
Battery internal resistance tester TOB-BK-300A |
|
Source voltage |
AC220V, 50HZ |
|
Power |
20W |
|
Advantages |
Suitable varies kinds battery and battery core Buzzer alarm Adjusting for-wire system |
|
Voltage test V1 |
Voltage range : 0-5V |
|
Minimum resolution : 0.001V |
|
|
Accuracy : ±0.002rdg+5dgt |
|
|
Voltage test V2 |
Voltage range : 5-20V |
|
Minimum resolution : 0.01V |
|
|
Accuracy : ±0.002rdg+5dgt |
|
|
Resistance test R1 |
Resistance range : 3—300 mΩ |
|
Testing current : 10mA |
|
|
Accuracy : ±0.003rdg+5dgt |
|
|
Resistance test R2 |
Resistance range :300—3000 mΩ |
|
Testing current : 1mA |
|
|
Accuracy : ±0.003rdg+5dgt |
|
|
Suitable batteries |
Lithium battery, lithium pouch cell(Lithium polymer battery), Nickel metal hydride, nickel cadmium battery, lead-acid battery and so on. |
|
Dimension |
340*380*110mm |
|
Weight |
3kg |
|
Warranty |
One Year limited warranty with lifetime support |
PACKAGE AND SHIPPING
|
1 Standard exported package : Internal anticollision protection, external export wooden box package 2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode 3 Responsible for the damage during shipping process, change the damage part for free 4 Supply with suitable voltage input and power plug according to customer's country requirements. |
SERVICES
|
1 We supply machines with battery technology support. 2 We can also supply a full set of materials for lithium battery including polymer battery, cylinder battery, mobile phone battery, EV battery. 3 We can also supply a full set of lithium battery equipment for lab research, pilot scale research and production line. 4 We can also supply a full set of battery technology for battery design, research and producing. |
