Beiben 2534 cargo truck supplier

Beiben 2534 cargo truck chassis, 6*4 drive, benz technology 7 Ton front axle, benz technology 16 T rear axle, europen technology weichai 340 hp engine, 12.00R20 tyre.





Beiben 2534 Cargo truck supplier in china

Best quality beiben 2534,2532,2538,2540,2542,2546 cargo trucks manufacturer is china CEEC TRUCKS plant. Beiben cargo truck for bulk goods like rice, vegetable,



beiben cargo truck


beiben cargo truck
Description

Technical Parameters

Brand BEIBEN TRUCK
Vehicle model 2534P
Cabin Full steel skeleton structure, covered with double layer steel plate
Anticorrosion treatment processes complex, anti-corrosion, durability of sustainable vehicles
Long/Day cab, made by full steel material, anti-crash performance can be ensured by double hollow chamber structure
Persons in cab: 3
Driving 6×4
Wheel base (mm) 4450+1450/5050+1450
Weight data Curb Weight(kg) : 11300
Engine Model Brand WeiChai WP10.336 / Diesel, Straight in line,water-cooled,turbocharged, intercooled, 6 cylinders,
Power 340HP
Emission EUR III
Rated power(kw/rpm) 247Kw/2200rpm
Transmission FAST GEAR Model:12JS160T 12-forward &2-reverse gears
Option:9JS150A
Clutch single disc, dry type, diaphragm spring, φ430
Frame BeiBen Unique frame, Mercedes-Benz technology, Strengthened frame
Fish belly, various width, various sections, side beam structure
Axle Front: Mercedes Benz Technology, 7.5 ton, non-driving steering axle
Middle/Rear: Mercedes Benz Technology, 13 Ton, ductile casting casing, with hub redactor, double reduction driving axle
Suspension Non-free standing stabilization spring, hydraulic shock absorber stabilization suspension
Steering ZJ120D/TAS85/ ZF8098 (Original ZF technology)
Wheels and tyre size 10+1/12.00-R20
Fuel tank (L) 400L
Up Body Volume(m) 7.5/8.0x2.3x0.8(m);
Colour Metal white, multi-colored options
