Product Description
The Beiben 2638 RHD tractor head is a heavy-duty tractor vehicle specifically designed for markets such as Tanzania. With its powerful towing capability, stable performance, and comfortable driving environment, it excels in long-distance transportation and heavy logistics. The vehicle features a 6x4 right-hand drive (RHD) configuration, making it suitable for traffic regulations in countries like Tanzania where driving is on the left side of the road. The cab type is NG80, equipped with an air-conditioned sleeper, providing a comfortable resting environment for the driver and ensuring fatigue is alleviated during long-distance driving.
The Beiben 2638 tractor truck is powered by a WEICHAI brand WP10.380E32 engine, with a power output of 380 horsepower (280 kW) and a maximum torque of 1600 Nm, delivered within a speed range of 1500-1800 RPM. The engine has a displacement of 9.726 liters and meets Euro III EGR emission standards. In terms of the transmission system, this tractor head adopts a FAST brand 12JS200T manual transmission gearbox, featuring 12 forward gears and 2 reverse gears, providing the driver with flexible gear shifting options. The clutch is a single-plate, diaphragm spring type with a diameter of Φ430 mm, ensuring reliable and durable transmission.
The Beiben RHD tractor head employs drum brakes and is equipped with a dual-circuit compressed air brake system and a service brake. The parking brake is a spring brake acting on the rear wheels. The auxiliary brake is of the WEVB type, and the vehicle is also equipped with an ABS anti-lock braking system, enhancing driving safety. The vehicle is fitted with a ZF brand TAS85 type steering gear, ensuring precise steering control. The frame is of a ladder structure with parallel straight beams, measuring 317x70x8.5+7+8 mm. The front suspension is a longitudinal leaf spring, and the rear suspension is an inverted leaf spring stabilizer suspension, providing a stable driving experience.
For the axles, the Beiben 2638 prime mover is equipped with BENZ technology axles. The front axle is a 6.5-ton BENZ type front axle, and the rear axle is a 13-ton BENZ type rear axle, both equipped with double reduction functionality. The axle ratio is 5.263, providing the vehicle with suitable torque output and travel speed.
Product Specifications
|
Beiben 2638 Tractor Head Parameters
|
|
Drive Type
|
6x4 RHD
|
|
Cab
|
|
Type
|
NG80
|
|
Equipment
|
One sleeper with air condition
|
|
Weight
|
|
|
Kerb mass (kg)
|
8800
|
|
GVW (kg)
|
25000
|
|
Towing weight (kg)
|
40000
|
|
The fifth wheel
|
90mm
|
|
Dimensions
|
|
Max. length(mm)
|
7100
|
|
Max. width(mm)
|
2500
|
|
Max. height(mm)
|
3305
|
|
Wheel base(mm)
|
3450+1450
|
|
Front wheel track(mm)
|
1995
|
|
Rear wheel track(mm)
|
1800/1800
|
|
Performance
|
|
|
Max. speed (km/h)
|
110
|
|
Max. gradeability(%)
|
30
|
|
Approach/Departure angel(°)
|
20/40
|
|
Engine
|
|
Brand
|
WEICHAI
|
|
Model
|
WP10.380E32
|
|
Power (kw/hp)
|
380HP/280KW
|
|
Max torque (N.M)/rpm
|
1600/1500-1800
|
|
Displacement (L)
|
9.726
|
|
Emission Standards
|
Euro III EGR
|
|
Transmission
|
|
Brand
|
FAST
|
|
Model
|
12JS200T
|
|
Control type
|
Manual
|
|
Gear Shift
|
12-forward & 2-reverse speeds
|
|
Clutch
|
|
Type
|
Single plate, diaphragm spring
|
|
Diameter (mm)
|
Φ430
|
|
Brakes
|
|
Type
|
Drum
|
|
Service Brake
|
With dual-circuit compressed air brake
|
|
Park Brake
|
Power spring brake acting on rear wheel
|
|
Auxiliary Brake
|
WEVB
|
|
ABS
|
With ABS
|
|
Steering
|
|
Brand
|
ZF TECHNOLOGY
|
|
Type
|
TAS85
|
|
Frame
|
|
Type
|
Ladder structure with parallel straight
|
|
Dimensions (mm)
|
317x70x8.5+7+8
|
|
Suspension
|
|
Front
|
Longitudinal leaf spring
|
|
Rear
|
Inverted leaf spring stabilizator suspension
|
|
Axles
|
|
Brand
|
BENZ
|
|
Front
|
BENZ TYPE: 6.5 ton front axle
|
|
Rear
|
BENZ TYPE: 13tons axle, double reduction
|
|
Ratio
|
5.263
|
|
Tire
|
12.00R20 radial tire
|
|
Fuel tank capacity(L)
|
400L
|
|
Electrics
|
|
Type
|
24V
|
|
Starter
|
5.58kw(24)
|
|
Generator
|
2.0kw(28V 70A)
|
|
Battery
|
2x135Ah
|
Product Details
