Beiben 4x2 towing truck 290hp truck head benz technology tractor truck

Beiben 4x2 towing truck 290hp truck head benz technology tractor truck,Beiben 4x2 towing truck 290hp
European security level
Stemping vehicle frame
Benz unique axle technique
High reliability



New BEIBEN North Benz NG80 4x2 heavy trailer truck tractor head camion hot sale in Africa low price

1. Best Chinese BEIBEN north benz 6x4 8x4 4x2 NG80/V3 Truck low price
2. Mercedes Benz Technology
3. Left handed drive and right handed drive available
4. High quality parts supply
5. Most professional service



Dimension

5995*2495*3095mm

Approaching angle/Departure angle

16/40°

Overhang(front/rear)

1410/1085mm

Wheel base

3500mm

Max speed

110km/h

Curb weight

5800kg

Max towing weight

35870kg

Max loading on fifth wheel, Permitted(kg)

12070kg

Slope climbing capability

Max.40%

Engine

Model

WP10.340E32,water-cooled,4 Strokes 6 cylinders in line,turbocharged, directly injection

Displacement

9.726L/Diesel

Stroke

126/130mm

Max. power

213/2200 (kw/rpm)

Max.torque

1160/1200-1600(Nm/rpm)

Emission stantard

Euro

Fuel tanker capacity

400L

Clutch

#420, Single dry frictional disc,Hydraulic boosting

Gearbox

9JS119B, mechanism,9 forward gears,1 reverse gear, manual operated

Gear ratio of gear box

11.02/6.55/4.64/3.36/2.71/1.95/1.38/1.00/0.81 R: 11.52

Suspension system

Front

Non-free standing leaf spring,telescopic shock absorber with stablizer bar suspension , 9pcs

Rear

Non-free standing stablization spring, balance suspension system, 9+6pcs

Brake system

Service brake

Brake gap can be adjusted automatically, double circulation air brake system

Assistant brake

Engine exhaust brake

Park brake

Potential springs pressing on middle and rear wheels

Steering system

D50,whole circulation in ball, hydraulic booster

Frame

Fish belly shape, variable width, variable sections

Front axle (Mercedes Technology)

Double-shoe pneumatic brake, non-driving steering axle

Middle and Rear axle (Mercedes Technology)

Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle

Tyre

315/80R22.5

Electrical system

Battery

2X12V/135Ah

Generator

28V-35A

Starter

5.4Kw/24V

Cabin

NG80B Long-Flat roof cabin with single sleeper
Full steel skeleton structure, covered with double layer steel plate;
Can be tipped forwardly;
High back seat for driver;Electric lifting window ;
With inner A/C
