Beiben 6*4 420HP V3 tractor truck
Traction type: 6x4
Driving type: Left hand drive
Cabin: Mercedes Benz (double Sleeper), with A/C, electric window lift.
Engine brand: Weichai EURO III
Engine model: WP12.420E32
Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & inter-cooling
Displacement: 11.6 liters
Max. Output: 420hp@2200rpm
Max torque: 1750NM@1200-1600rpm
Bore/Stroke (mm):126/155
Gear box:Fuller 12 speeds (12JSD200TA)
Steering: D50
Clutch: Φ430 diaphragm type
Front axles: Benz 6.5T front axle
Rear axles: Benz double reduction drive axle
Ratio: 4.2 (4.769, 5.263 is optional)
Tyre: 315/80R22.5 radial tires 10+1
Spring: 3/4, 9/13
Fuel tank capacity (L): 400
Max. speed (km/h): 110
Kerb. mass: 8800 kg
Total mass: 25000kg
Wheel base (mm): 3200+1350
Front overhang (mm): 1515
Rear overhang (mm): 840
Front track (mm): 2045
Rear track (mm): 1800/1800
Approach angle: 16 degree
Departure angle: 60 degree
Dimension (mm): 6905x2500x3800
5TH wheel: 3.5’’ (JOST is optional)
