Beiben 6*4 fuel tanker trucks are mostly produced on beiben 2527 fuel tanker truck chassis, this kind of beiben 10 wheeler fuel tanker truck can payload at least 15 cbm fuel , oil or gas.
Beiben 6*4 fuel tanker
| MIAN PARAMETER
|
| GVW(kg)
|
31960
|
Tank Capacity(m³)
|
25
|
| Payload weight(kg)
|
20000
|
Overall dimension
|
9450*2500*3050 (mm)
|
| Curb weight(kg)
|
11735
|
Tank dimention
|
/
|
| Approaching/Departure Angle(°)
|
12/13
|
Front/Rear suspension(mm)
|
1410/2190
|
| Axles No.
|
3
|
Wheelbase(mm)
|
4500+1350
|
| Rated person of Cab
|
3
|
Max. speed(km/h)
|
110
|
| CHASSIS PARAMETER
|
| Model
|
ND1253B45J
|
Brand
|
Beiben
|
| Tire Nos.
|
10+1(spare)
|
Tire Spec.
|
10.00-20
|
| Leaf Spring No.
|
9/10
|
Front Trace(mm)
|
1940
|
| Fuel Type
|
Diesel
|
Rear Trace(mm)
|
1847/1847
|
| Emission Standard
|
Euro 2/Euro 3
|
| ENGINE MODEL
|
DISPLACEMENT (ml)
|
POWER (kw)
|
| WP7.270E30
|
7140
|
199
|
