| Benz design platform. widely exported to middle east,africa,south America |
Cabin
|
air-condition ,single or double sleeper, USB application,
Benz cabin,air suspension seat.adjustable steering wheels. |
| Drive type |
Left hand / right hand, 4x2,6x2,6x4,8x4,6x6. |
| Engine : WEICHA I(Steyr technology) |
Type
|
Diesel 4-stroke,direct injection,6 cylinder in line engine,
water cooling, turbo-charging& inner cooling. |
| Number of cylinder |
six |
Chinese oil pump, option:BOSCH oil pump |
| Displacement |
5.762L, |
11.596L |
| Emission |
Euro |
2,3,4 |
| Max torque (kg.m/rpm) |
Max 2000NM@1400-1600rpm |
| Clutch |
Type
|
φ 430 diaphragm type |
| Single-plate dry cluth,mechanically operating with air assisted |
| Gear box ,Transmission |
| Model |
FAST FULLER(recommendation), ZF |
| Type |
9,10,12,16 speeds option:( Automatic Synchronizer ) |
| Steering |
ZF8098 |
| Front axle |
| Type |
BENZ technology axle |
| Permissble load |
Kg |
7000kg/ 7500kg |
| Rear driving axle |
| Model |
Benz technology driving axle, |
| Type |
Pressed axle housing,single/double reduction . |
| Permissble load |
Kg |
1 3000kg/16000 kg |
| Track (mm) |
1800/1860 |
| Tyre : |
8.25R-20,11.00-20,12.00-20,12.00R-20,315/80R-22.5 |
| Hydraulic system(lifting system): HYVA |
| Braking sytstem |
Double lines penumatic (air ) brake, drum brake,option: disc brake |
| Length of dump body(mm): 4.2m-9.0m |
| Engine Brake |
|
EVB |
| Parking brake |
Spring activated,compressed air operating on rear wheels |
| |
|
| Suspension system |
| Type |
FR/RR |
Leaf Spring, 10/12 |
| Electric equipment |
| Operating voltage |
24v,negative grounded |
| Battery voltage/capacity |
2x 12v/135A,165A |
| Starter |
5.4KW/24V |
| Oil Tank : 380L ,400L |
| Dimension of King pin(5th wheel): 50(2’’),90(3.5’’). |
| PTO: (QH50) |
