The system provides an output voltage that is directly proportional to thedistance between the probe tip and the observed conductive surface and can
measure both static (position) and dynamic (vibration) values. The system’sprimary applications are vibration and position measurements on fluid-film
bearing machines, as well as Keyphasor* reference and speed measurements3.
The 3300 XL 8 mm system delivers the most advanced performance in our eddycurrent proximity transducer systems. The standard 3300 XL 8 mm 5-metre
system also fully complies with the American Petroleum Institute’s (API) 670Standard (4th Edition) for mechanical configuration, linear range, accuracy, and
temperature stability. All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes,
extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.Each 3300 XL 8 mm Transducer System component is backward-compatible and interchangeable4 with other non-XL 3300 series 5 mm and 8 mm transducer system components5. This compatibility includes the 3300 5 mm probe, forapplications in which an 8 mm probe is too large for the available mounting
|
