Product Description：
The 3300 XL 11 mm Proximitor Sensor has the same advanced features found in
the 3300 XL 8 mm Proximitor Sensor. Its thin design allows it to be mounted in
either a high-density DIN-rail installation or a more traditional panel mount
configuration. Improved RFI/EMI immunity allows the 3300 XL Proximitor Sensor
to achieve European CE mark approvals without any special mounting
considerations. This RFI immunity also prevents the transducer system from
being adversely affected by nearby high frequency radio signals. SpringLoc
terminal strips on the Proximitor Sensor require no special installation tools and
facilitate faster, highly robust field wiring connections.
The 3300 XL 11 mm Proximitor Sensor is designed to replace the 7200-series 11
mm and 14 mm Transducer Systems. When upgrading from the 7200-series
system to the 3300 XL 11 mm system, every component must be replaced with
3300 XL 11 mm components. In addition, the monitoring system must be
updated. If using a 3500 Monitoring System, an updated version of the
configuration software that lists the 3300 XL 11 mm Transducer System as a
compatible option is required. Existing 3300 Monitoring Systems may need a
modification. Contact your local sales and service representative for assistance.
