Product Description：
The 3300 XL NSv Proximity Transducer system is intended for
use with centrifugal air compressors, refrigeration
compressors, process gas compressors and other machines
with tight installation requirements. The 3300 XL NSv Proximity
Transducer System consists of:
-a 3300 NSv probe
-a 3300 NSv extension cable
-a 3300 XL NSv Proximitor Sensor
The primary uses for the 3300 XL NSv Transducer System are
for areas where counter bore, sideview or rearview restrictions
limit the use of standard Bently Nevada 3300 and 3300 XL 5
and 8 mm Transducer Systems. It is also ideal for small target
applications, such as measuring radial vibration on shafts
smaller than 51 mm (2 in) or axial position on flat targets
smaller than 15 mm (0.6 in). It is primarily used in the
following applications on fluid-filmed bearing machines
where a small shaft or reduced side-view is present:
-Radial vibration and radial position measurements
-Axial (thrust) position measurements
-Tachometer and zero speed measurements
-Phase reference (Keyphasor signals)
