Bently nevada Diagnostics Access Panel 3500/08
|
|
3500/08 Types
|
The Bently Nevada 3500/08 Diagnostics Access Panel is part of the Bently Nevada 3500 series, designed to provide convenient system diagnostics access.
|
|
This module offers users an easy way to access diagnostic information through the front panel, allowing for monitoring and maintenance of the system's status.
|
|
The Diagnostics Access Panel enables direct access to signals from the 3500 System without opening cabinet doors and subjecting electronic equipment to the risk of EMI/RFI exposure, or other harsh environmental conditions.
|
|
Parts delivered worldwide
|
Award-winning service
|
More than 25 in stock
|
Full 12-month warranty
|
We deliver worldwide
|
Description：
The Diagnostics Access Panel is designed for use with the Bently Nevada 3500 Series Machinery Protection System. While the 3500 rack provides front-panel access to all buffered transducer and Keyphasor outputs, there are
installations for which these front-panel connections are inconvenient or impractical to use. One example is that of a 3500 rack installed in an EMI-shielded or weatherproof enclosure.
The Diagnostics Access Panel connects to the 3500 System’s dynamic data port through a 4.6-metre (15-foot) signal cable. The signals available on a column of connectors will vary depending on the 3500 System configuration.
Specifications：
Interface：One 3500/08 can deliver signals from six 3500 4-channel monitors and one 3500 2-channel Keyphasor Module. The Diagnostics Access Panel has one coaxial connector for each channel. The maximum cable length for use with the 3500/08 is 26 metres (85 feet). When 3500/08 is used with a 3500/22, TDI, a Buffered Signal Output Module is required to provide access to all of the buffered signals.
Environmental Limits
Operating Temperature：-30°C to +65°C(-22°F to +150°F)
Storage Temperature：-40°C to +85°C(-40°F to +185°F)
Humidity：95% non-condensing
