Bently nevada Proximitor Monitor 3500/40M-01-01

Bently nevada Proximitor Monitor 3500/40M-01-01

Part Number: 3500/40M-01-01
Manufacturer: Bently Nevada
Series: 3500
Operating Temperature: -30 to +65 degrees Celsius
Storage Temperature: -40 to +85 degrees Celsius
Power consumption: 7.7 watts
Humidity: 95%, noncondensing
Product type: Proximitor Monitor
Availability: In Stock
Country of Manufacture: United States (USA)

3500/40M-01-01 is a proximitor Monitor designed and developed by Bently Nevada. The proximitor Monitor is a four-channel monitor that accepts input from proximity transducers from Bently Nevada, conditions the signal to provide various vibration and position measurements, and compares the conditioned signals to user-programmable alarms. It condition input signals effectively. By doing so, it transforms raw data into a range of valuable measurements. These measurements encompass not only vibration data but also critical position measurements. This versatility is particularly advantageous for industries where comprehensive insights into machinery behavior are essential for predictive maintenance and operational optimization. The Proximitor Monitor offers users the flexibility to set custom alarms according to their specific operational requirements. These alarms serve as a safeguard, promptly notifying operators and maintenance personnel of any deviations from predefined thresholds. By providing real-time alerts, this monitor plays a pivotal role in preventing potential issues before they escalate, thus minimizing downtime and reducing maintenance costs.

Configurable Functions
-Eccentricity Measurement: The monitor can assess and report on eccentricity, helping operators identify any deviations from optimal shaft alignment, a critical factor in machinery reliability.
-Radial Vibration Analysis: Precise monitoring of radial vibration allows for early detection of irregularities that could lead to equipment failure, enabling timely intervention.
-REBAM (Reverse-Eccentricity Bore Alignment Monitor): This function aids in assessing the alignment of machine components, ensuring that they meet the necessary standards for safe and efficient operation.
-Thrust Position Monitoring: Keeping tabs on thrust position is crucial in industries where axial forces play a pivotal role. Monitoring this parameter helps prevent premature wear and tear.
-Differential Expansion Measurement: This function helps monitor the expansion and contraction of critical machine components, ensuring they remain within acceptable limits.
