The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.
The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-meter system also fully complies with the American Petroleum Institute’s (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.
Each 3300 XL 8 mm Transducer System component is backward compatible and interchangeable4 with other nonXL 3300 series 5 mm and 8 mm transducer system components. This compatibility includes the 3300 5 mm probe, for applications in which an 8 mm probe is too large for the available mounting space
FAQ:
1. What type of cable is used with this probe?
The probe uses a 75Ω coaxial cable with fluoroethylene propylene (FEP) insulation, ensuring that it remains durable and resistant to harsh environmental conditions, such as high heat, moisture, and chemicals.
2. What is the significance of the "unthreaded length" specification?
The "unthreaded length" refers to the portion of the probe shaft that does not have threads. In this model, the unthreaded length is 0 mm, indicating that the probe shaft is entirely threaded or mounted to the required specifications without any unthreaded portion.
3. Can the 330102-05-40-05-02-05 be used in hazardous environments?
Yes, Bently Nevada proximity probes are designed to be used in hazardous locations, provided that the proper safety certifications and installation guidelines are followed. Always check the specific installation and certification requirements for your environment.
