Benz technology 15ton dump truck Beiben 6x4 tipper lorry

Benz technology 15ton dump truck , based on germany benz 15 T dump truck chassis, best quality for benz 1927 trucks.



BENZ TECHNOLOGY 15ton DUMPT RUCK



Sales No. 2629K
Dimension(mm) Long 7690
  Wide 2495
  High 2975
Wheel base(mm) 3800+1450
Drive 6×4
Engine Model WP10.290E32/WP10.290
Cabin NG80B/ short cab
Clutch(mm) Φ430
Front Axle 7.5T
Rear/Mid Axle Model/speed radio Double Reduction Driving Axle /5.263
Steering System ZF8098
Braking System Dual Circulation Air Brake System
Fuel Tank(L) 400L
Frame/mm 317×70×8.5+7+8mm
Tire 12.00R20
Front/Rear Overhang 1410/1034
Transmission Fuller 9JS150TA
Curb Weight(kg) 9100
Up Body Volume(m³) 5.6mx2.3mx1.3m
Max Speed(km/h) 90
