Big Battery Dropping Test Machine For Lithium Battery Safety Performance Testing
SPECIFICATIONS
|
Type
|
TOB-BF-F-315S
|
TOB-BF-F-320S
|
|
Drop height
|
300~1500mm Adjustable
|
300~2000mm Adjustable
|
|
Dimension
|
W1200*D1700*H2400mm
|
W1200*D1700*H2900mm
|
|
Weight
|
About 750kg
|
About850kg
|
|
Max battery weight
|
0~70KG
|
|
Max battery size
|
W800*D600*H800mm
|
|
Carriage arm size
|
W290*D180*H8mm
|
|
Display
|
Digital Display 、Adjustable
|
|
Test mode
|
Side、edge、corner drop-full range
|
|
Drop plate material
|
Steel plate(Hard wood/Marble slab/Acrylic sheet/
Cement board optional)
|
|
Dropping way
|
Electric drop
|
|
Up and down way
|
Electric lift
|
|
Power supply
|
AC220V 50HZ
|
|
Power
|
0.5KW
|
