Button super capacitor automatic production line
SPECIFICATIONS
Functional overview
The production line is set automatically into the positive case, the negative case, the pole piece, the diaphragm,
liquid injection, positive and negative combinations, fill pressure, sealing as one of the fully automated production lines.
According to the user's process requirements, development, and manufacturing sections of semi-automatic production lines.
Technical parameters
|
Supercapacitor monomer diameter
|
φ6.8 ~ 24.5mm
|
|
Supercapacitor monomer height
|
1.6 ~ 3.0rnm
|
|
Pole piece width
|
8 ~ 200mm
|
|
For the separator roll diameter
|
<diameter 450mm
|
|
For pole piece roll diameter
|
<diameter 450mm
|
|
For pole piece of material size
|
<200 * 200mm
|
|
Production capacity
|
200pcs / min
|
|
Total power
|
6KW
|
|
The gas supply
|
0.4 ~ 0.7MPa
|
|
Power
|
220V / 380V
|
|
Dimensions (L * W * H)
|
7200 * 1350 * 1520mm
|
